Plate dimensions 250x250 mm
Plate type : Chamber type
Plate material : Polypropylene
Number and volume of licence plates : 12 pieces
Filter cloth : Special for ceramic mud (PP)
Total Capacity : 15 lt. Sludge
Total Capacity : (Cake Weight) 25 Kg. (Density is 1.7 according to Ceramic Sludge)
Charging Time : Approximately 1 hour
CHASSIS SPECIFICATIONS
Material : St 37 Carbon Steel Head End Thickness: 40 mm.
Surface protection : Electrostatic Painted
Filtrate Outlet : Open discharge
Drainage water channel : St -37 + Electrostatic Painted
Filter arms : Chrome Plated induction Shaft
Power : 1,5 KW.
Plate clamping : Manual, Hydraulic
Licence plate purging : Manual
Hydraulic clamping pressure : 100-300 bar
CE Certified.
2 Year Warranty against workmanship defects
OPTIONAL
1. Pulley mixer
2. Pump
PUMP SPECIFICATIONS
Connection Input-Output: 1’
Connection Type: Gear
Capacity Range: 0 - 160 lt/min
Pressing Distance: 0 - 84 mss
Max. Suction Height: 6 - 8 m
Max. Solid Part Size: 4 mm
Pump Body Materials: Aluminium, Cast Iron, Stainless Steel (316)
Pump Internal Materials: Neoprene, Buna-n, Teflon, Viton, Santoprene, EPDM
Air Line Aluminium (Middle Core, Air Valve, Pilot Valve, Air Inlet Cover, Inner Covers)
Air Connection: 1/2’
Air Working Pressure: 0-8,4 bar
Air Consumption: 10 - 67 m3/h
